Image Processing of Edge and Surface Defects: Theoretical Basis of Adaptive Algorithms with Numerous Practical Applications

ISBN-13: 9783642260353 / Angielski / Miękka / 2012 / 168 str.

Roman Louban

Opis

The human ability to recognize objects on various backgrounds is amazing. Many times, industrial image processing tried to imitate this ability by its own techniques. This book discusses the recognition of defects on free-form edges and - homogeneous surfaces. My many years of experience has shown that such a task can be solved e?ciently only under particular conditions. Inevitably, the following questions must be answered: How did the defect come about? How and why is a person able to recognize a speci?c defect? In short, one needs an analysis of the process of defect creation as well as an analysis of its detection. As soon as the principle of these processes is understood, the processes can be described mathematically on the basis of an appropriate physical model and can then be captured in an algorithm for defect detection. This approach can be described as "image processing from a physicist's perspective." I have successfully used this approach in the development of several industrial image processingsystemsandimprovedupontheminthecourseoftime.Iwouldlike to present the achieved results in a hands-on book on the basis of edge-based algorithms for defect detection on edges and surfaces. I would like to thank all who have supported me in writing this book.

Recenzje

Aus den Rezensionen: "... Die HeIligkeitsverhältnisse an der Kante einer Materialbeschädigung werden als Gauß'sche Verteilung einer Strahlung interpretiert und in einem physikalischen Modell erfasst. Basierend auf diesem Modell wurden neue Methoden entwickelt, mit denen unterschiedliche Fehlertypen unabhängig von den Helligkeitsbedingungen eines aufgenommenen Bildes ermittelt werden können. ... Zahlreiche Anwendungsbeispiele veranschaulichen die theoretischen Ausführungen." (in: QZ Qualität und Zuverlässigkeit, March/2010, Issue 3, S. 13)

Spis treści

Edge Detection.- Defect Detection on an Edge.- Defect Detection on an Inhomogeneous High-Contrast Surface.- Defect Detection on an Inhomogeneous Structured Surface.- Defect Detection in Turbo Mode.- Adaptive Edge and Defect Detection as a basis for Automated Lumber Classification and Optimisation.- Object Detection on Images Captured Using a Special Equipment.- Before an Image Processing System is Used.

O autorze

Born on February 26, 1954 in Kiev, Ukraine.

1971 – 1976 Study at the State University of Woronezh, Russia. Graduation: Qualified physicist with award.

1977 – 1992 Scientific research at the Institute of Material Problems of the Science Academy, Kiev, Ukraine. Area of studies: plasma physics, composed materials.

1987 Promotion with the grade: Doctor of Engineering Sciences

1992 – 2006 hema electronic GmbH, Aalen, Department: machine vision, Development engineer, Project director. Main topic: Algorithmics for defect recognition on edges and surfaces

Since April 2006 Thermosensorik GmbH, Erlangen, Manager Software Engineering, IP Expert

Blurb

The edge and surface inspection is one of the most important and most challenging tasks in quality assessment in industrial production. Typical defects are cracks, inclusions, pores, surface flakings, partial or complete tears of material surface and s.o. These defects can occur through defective source material or through extreme strain during machining process.

Detection of defects on a materialc surface can be complicated due to extremely varying degrees of material brightness or due to shadow areas, caused by the folding of the surface. Furthermore, impurities or surface discolourations can lead to artefacts that can be detected as pseudo-defects.

The brightness conditions on the edge of material defects are interpreted as a Gauss distribution of a radiation and used for a physical model. Basing on this model, an essentially new set of adaptive edge-based algorithms was developed. Using these methods, different types of defects can be detected, without the measurements being dependent on local or global brightness conditions of the image taken. The new adaptive edge-based algorithms allow a defect detection on different materials, like metal, ceramics, plastics and stone.

These methods make it possible to explicitly detect all kinds of different defects independently of their size, form and position and of the surface to be inspected. The adaptive edge-based methods provide a very wide spectrum of applications.
