Phase Angle Measurement Using a Pll » książka
Phase Angle Measurement Using a Pll
ISBN-13: 9783659289125 / Angielski / Miękka / 2012 / 80 str.
Phase angle measurement between two AC waveform having same frequency is needed in various applications like 3-phase transformer connection, CT and PT installation, Power factor determination. Conventional phase angle meters are bulky and costly.A new method for measuring phase angle using a digital PLL is proposed with operating frequency range of 20Hz to 1kHz. This design also has lag/lead identification feature and is cost effective.The phase angle meter involves phase detection using PLL, frequency to voltage conversion, calibration and display.A regulated power supply and a phase shifter circuit are also designed to test the phase angle meter.A 3 1/2 digit LED display panel meter is used to display the final measured phase difference between two AC waveforms fed as inpu
Phase angle measurement between two AC waveform having same frequency is needed in various applications like 3-phase transformer connection,CT and PT installation,Power factor determination. Conventional phase angle meters are bulky and costly.A new method for measuring phase angle using a digital PLL is proposed with operating frequency range of 20Hz to 1kHz. This design also has lag/lead identification feature and is cost effective.The phase angle meter involves phase detection using PLL, frequency to voltage conversion, calibration and display.A regulated power supply and a phase shifter circuit are also designed to test the phase angle meter.A 3 1/2 digit LED display panel meter is used to display the final measured phase difference between two AC waveforms fed as input.
