Multiband Monopole and Microstrip Patch Antennas for GSM and Dcs Bands

ISBN-13: 9783846539514 / Angielski / Miękka / 2011 / 132 str.

Giannakopoulos Georgios

Opis

This book is mainly concerned with the design, construction and testing of a dual-band monopole microstrip patch antenna. A discussion of general antenna theory is included with some basic microstrip antenna theory for rectangular patches is introduced leading to formulas which are computed using the MAPLE computer algebra package. The design of compact monopoles, suitable for mobile phone use, is discussed with particular emphasis on dual-band monopoles. A suitable dual-band monopole is chosen to be analyzed in detail using the Ansoft High Frequency Structure Simulator (HFSS) package. The HFSS package is introduced and tested on a basic rectangular patch antenna to confirm well known results in the theory and literature. A dual-band monopole antenna is fabricated on a microstrip in the laboratory in both unwrapped form and wrapped form using the Proteus ARES package for automatic construction of the PCB boards. The multiband monopole and the microstrip patch antenna are tested in the laboratory of the University. The results are compared with the HFSS results and shown to be in general agreement with each other.

O autorze

Georgios Giannakopoulos was born in 1981 in Athens, Greece. He received a B.Eng., (Hons) degree in Communications Engineering from the University of Plymouth, UK in 2007. Then, he received an M.Sc., degree within Electronics, Communications Engineering and Signal Processing in September 2008 from the same University.
