Handbook of Force Transducers: Principles and Components

ISBN-13: 9783662506844 / Angielski / Miękka / 2016 / 612 str.

Dan Mihai Stefanescu

Opis

Setting out the principles and methods of force measurement, this volume then assesses the components of strain-gauge force transducers, including digital and intelligent subsystems, the `elastic element' and the Wheatstone bridge in parametrical transducers.

Spis treści

INTRODUCTION.- ELECTRICAL METHODS OF FORCE MEASUREMENT.- RESISTIVE FORCE TRANSDUCERS.- INDUCTIVE FORCE TRANSDUCERS.- CAPACITIVE FORCE TRANSDUCERS.- PIEZOELECTRIC FORCE TRANSDUCERS (PZFTs).- ELECTROMAGNETIC FORCE TRANSDUCERS.- ELECTRODYNAMIC FORCE TRANSDUCERS.- MAGNETOELASTIC FORCE TRANSDUCERS.- GALVANOMAGNETIC FORCE TRANSDUCERS.- VIBRATING WIRE FORCE TRANSDUCERS.- RESONATOR FORCE TRANSDUCERS.- ACOUSTIC FORCE TRANSDUCERS.- GYROSCOPIC FORCE TRANSDUCERS.- FORCE BALANCE TECHNIQUES.- MIXED METHODS IN FORCE MEASUREMENTS.- WHEATSTONE BRIDGE - THE BASIC CIRCUIT FOR STRAIN GAUGE FORCE TRANSDUCERS.- STRAIN GAUGES ELECTRONIC CIRCUITS.- CLASSIFICATION OF ELASTIC ELEMENTS.- STRETCHED / COMPRESSED COLUMNS.- STRETCHED / COMPRESSED TUBES.- BENT LAMELLA (CANTILEVER BEAMS).- BENT AND/OR TORSION SHAFTS... .

Blurb

Part I introduces the basic "Principles and Methods of Force Measurement" according to a classification into a dozen of force transducers types: resistive, inductive, capacitive, piezoelectric, electromagnetic, electrodynamic, magnetoelastic, galvanomagnetic (Hall-effect), vibrating wires, (micro)resonators, acoustic and gyroscopic. Two special chapters refer to force balance techniques and to combined methods in force measurement.

Part II discusses the "(Strain Gauge) Force Transducers Components", evolving from the classical force transducer to the digital / intelligent one, with the incorporation of three subsystems (sensors, electromechanics and informatics). The elastic element (EE) is the "heart" of the force transducer and basically determines its performance. A 12-type elastic element classification is proposed (stretched / compressed column or tube, bending beam, bending and/or torsion shaft, middle bent bar with fixed ends, shear beam, bending ring, yoke or frame, diaphragm, axial-stressed torus, axisymmetrical and voluminous EE), with emphasis on the optimum location of the strain gauges. The main properties of the associated Wheatstone bridge, best suited for the parametrical transducers, are examined, together with the appropriate electronic circuits for SGFTs.

The handbook fills a gap in the field of Force Measurement, both experts and newcomers, no matter of their particular interest, finding a lot of useful and valuable subjects in the area of Force Transducers; in fact, it is the first specialized monograph in this inter- and multidisciplinary field.
