Gate Diffusion Input (GDI) Technique

ISBN-13: 9786136569994 / Angielski / Miękka / 2018 / 60 str.

Saman Ziabakhsh Shalmani; Sanam Sohrabi Aji Bisheh; Soheyl Ziabakhsh Shalmani

Opis

This book introduces a Gate Diffusion Input (GDI) methodology as an alternative approach in digital circuits. In this technique, a wide range of complex logic functions can be realized by using a lower number of CMOS transistors. The advantages of using GDI technique are multi-folded. The first is to implement digital gates (i.e. inverters, NAND, NOR, XOR, XNOR, buffers, etc.) with very low propagation delay and high logic level swing. As a second advantage, the GDI-based circuits consume lower power consumption and chip area compared with the CMOS equivalent. This provides a new implementation of digital circuits which are suitable for longer-lasting portable devices, like smartphones, tablets, IoT, etc.. A third advantage is the simplicity of circuit design by using very small cell library. In this book, after a brief review of GDI specifications, we will discuss different architectures of GDI-based digital circuits that have been recently proposed.

O autorze

Saman Ziabakhsh is M.Sc. student at University ofGuilan, Iran.Sanam Sohrabi received the M.Sc degree in Electrical Engineering from the University of Guilan, Iran in 2010. She works as a researcher at MERDCI, Tehran, Iran.Soheyl Ziabakhsh is working toward his Ph.D. degree in the Department of Electrical Engineering at ETS, Montreal, Canada.
