From Code to Chip

ISBN-13: 9783031685644 / Angielski / Miękka / 2026 / 120 str.

Jakob Ratschenberger; Harald Pretl

Opis

This book shows how the layout of an analog circuit can be automatically generated in a fully open-source way. Based on an exemplary design flow, it introduces and explains the necessary steps for transforming a SPICE netlist into a layout, which can be inspected by the open-source layout editor Magic VLSI. This is done by using the industry's first open-source process design kit SKY130. Furthermore, the implementation of the design flow in the programming language Python is available as open-source on GitHub.
