Electromagnetic Modeling of Planar Array Structures

ISBN-13: 9783845403557 / Angielski / Miękka / 2011 / 140 str.

Aamir Rashid

Opis

Large sized planar structures are increasingly being employed in satellite and radar applications. But due to large electrical size and complex cellular patterns of modern designs, full-wave analysis of these structures requires enormous memory and processing requirements. Therefore conventional techniques based on linear meshing either fail to simulate such structures or require resources not available to a common antenna designer. A novel technique called Scale-changing Technique (SCT) addresses this problem by partitioning the cellular array geometry in numerous nested domains defined at different scale-levels in the array plane. Multi-modal networks, called Scale-changing Networks (SCN), are then computed to model the electromagnetic interaction between any two successive partitions. The cascade of these networks allows the computation of the equivalent surface impedance matrix of the complete array which in turn can be utilized to compute far-field scattering patterns. Since the computation of scale-changing networks is mutually independent, execution times can be reduced significantly by employing multiple processing units.

O autorze

Aamir Rashid was born in Sargodha, Pakistan, in 1981. He completed his doctorate degree from University of Toulouse (INP Toulouse), France in 2010. His research interests include computational electromagnetic modeling using Method of Moments and Domain Decomposition Techniques.
