Compensation Systems for Low Temperature Applications

ISBN-13: 9783642060663 / Angielski / Miękka / 2010 / 291 str.

Balzej T. Skoczen

Opis

The present monograph is mainly focused on the behaviour of ductile ma terials at cryogenic temperatures, stability issues concerning application of corrugated shells at cryogenic conditions and reliability oriented parametric optimisation of compensation systems containing the corrugated bellows. As there are relatively few publications on combined material and structural be haviour at very low temperatures, the monograph aims at filling this gap. It is worth pointing out that within the class of publications dedicated to low temperature behaviour of materials and structures the majority is based on testing down to the temperature of liquid nitrogen (77 K). Rare publications deal with the analysis of material and structural response at the temperature of liquid helium (4. 5 K) or superfluid helium (below the point T>., = 2. 17 K). This can be explained by the fact that an (by its nature complex) installation for testing at such low temperatures is very expensive. Only the large research centres and universities, working in the domain of superconductivity, cryogen ics or developing superconducting magnets for particle accelerators, can afford such installations. A significant part of the present monograph is dedicated to the analy sis of the phenomena associated with plastic yielding in stainless steels at cryogenic temperatures. Generally, three phenomena are distinguished: plas tic strain induced phase transformations, serrated yielding and evolution of ductile damage."

Spis treści

1 Introduction to the Compensation Systems.- 2 Thermodynamics of Processes Occurring in Metals at Low Temperatures.- 3 Properties of Austenitic Stainless Steels at Cryogenic Temperatures.- 4 Plastic Yielding and Evolution of Ductile Damage under Cryogenic Conditions.- 5 Strain Induced Martensitic Transformation at Low Temperatures.- 6 Stability of Corrugated Axisymmetric Shells (Bellows).- 7 Material and Fatigue Induced Structural Instabilities of Corrugated Bellows at Low Temperatures.- 8 Reliability Oriented Optimum Design Of Cryogenic Compensation Systems.- 9 Applications: Accelerators for High Energy Physics and Cryogenics Transfer Lines.- References.

Blurb

The book is dedicated to the behaviour of ductile materials at cryogenic temperatures, structural stability issues and reliability oriented parametric optimisation of compensation systems containing the corrugated bellows. The problems of local and global stability of systems containing bellows, coupling between the low-cycle fatigue and stability as well as evolution of plastic strain fields, micro-damage and strain induced phase transformation in the corrugated shells at cryogenic temperatures are presented. As a special feature reliability oriented optimum design of compensation systems under strength, stability, fatigue and geometrical constraints is discussed. The relevant applications in the particle accelerators and cryogenic transfer lines are shown.
