Accessories for Hv and Ehv Extruded Cables: Volume 2: Land and Submarine AC/DC Applications

ISBN-13: 9783030804053 / Angielski / Twarda / 2023

Pierre Argaut

Spis treści

12         Guidelines for safe work on AC cable systems under induced voltages or current

12.1      Introduction

12.2      Definition of induced voltages

12.3      Principles of safe work

12.4      Work procedures

12.5      Working conditiond

12.6      Methods of Calculation

12.7      Conclusion

12.8      Bibliography/References

13         Recommendations for testing of long AC Submarine Cables with Extruded Insulation for System Voltage above 30(36) to 500 (550) kV

13.1      Introduction

13.2      Definitions

13.3      Current technologies for submarine cable designs

13.4      Current technologies for submarine joint designs

13.5      General aspects on submarine cable testing

13.6      Routine Test

13.7      Sample Test

13.8      Type Test on Cable System

13.9      Prequalification Test

13.10    Extension of Qualification Test

13.11    Electrical tests after installation

13.12    References

13.13    Appendices

14         Accessories in Transitions from Overhead to Underground

14.1      Transition in Compounds/Substations

14.2      Transition on Towers/poles

15         Accessories in Large Cross-Section Cable Systems

15.1      Scope and definitions

15.2      Introduction

15.3      Rigid Installations

15.4      Flexible installations

15.5      transition between rigid and flexible Systems

15.6      Duct installations

15.7      Short-circuit forces

15.8      Cleat applications

15.9      Mechanical cable parameters

15.10    Conclusions

15.11    Bibliography/References

15.12    Annexes

16         Recommendations for mechanical testing of submarine cables and their accessories

16.1      Introduction

16.2      Definitions

16.3      Mechanical handling of submarine cables

16.4      General aspect of mechanical testing

16.5      type tests

16.6      Project specific tests and special tests

16.7      Bibliography/references

16.8      Annexes

17         Recommendations for testing DC extruded cable systems for power transmission at a rated voltage up to 500 kV.

17.1      Introduction

17.2      Development tests

17.3      Prequalification tests

17.4      Type Tests

17.5      Routine tests

17.6      Sample tests

17.7      After installation tests

17.8      References

17.9      Appendices

18         Recommendations for Testing DC Transition Joints for Power Transmission at a Rated Voltage up to 500kV.

18.1      Introduction

18.2      Definitions

18.3      Development Tests

18.4      Routine Test

18.5      Sample Test

18.6      Type Test

18.7      Prequalification Test

18.8      Electrical Test after Installation

18.9      References

18.10    Appendix

19         Surge Voltage Limiters and Link Boxes

20         Maintenance and remaining life management of accessories

20.1      Maintenance

20.2      Remaining life management

21         New Work Items

21.1      HVAC

21.2      HVDC

O autorze
